Durlon® 9400
Durlon®
In applications where highly aggressive products are present, the Durlon® 9400 is recommended. It contains carbon particles offering a greater flexibility and excellent sealing properties without losing its PTFE properties.
Downloads
Applications
- Highly aggressive chemicals (including hydrofluoric acid)
- Industries: Chemical processing, Food and beverage, Pulp and paper, Petrochemical
Specifications
Technical Data
| Color | Black |
|---|---|
| Temperature | Minimum: -212°C(-350°F), Continuous: 260°C(500°F), Short term: 288°C(550°F) |
| Pressure | 1500psi |
| Compressibility | 5-12% |
| Recovery | 40% |
| Creep relaxation | 30% |
| Tensile strength | 2100 psi |
| Nitrogen sealability | 0.01cc/min |
| "Gasket factor" m | 1/16": 6.8 |
| Gasket factor y | 1/16": 2765psi |
| Gasket factor Gb | 1/16": 1701psi. 1/8": 1412psi |
| Gasket factor a | 1/16": 0.173, 1/8": 0.164 |
| Gasket factor Gs | 1/16": 99psi, 1/8": 248psi |
N.B. The information presented may differ from practice. We recommend conducting tests according to the conditions of use. We accept no responsibility for results obtained by the application of this information or the safety and suitability of our products. The data is subject to certain variations without notice.
