SK565
Muscovite mica sk565
The Mica SK565 sheet is made from a mica muscovite paper with a silicone base adhesive specially designed for high temperatures up to 1472°F.
Downloads
Applications
Because of its good dielectric resistance, this material is used to fabricate dielectric flanges in fonderies and aluminum smelters.
Specifications
Technical Data
| Thickness (mm) | 1.5 to 30.0 |
|---|---|
| Density (g/cm³) | 1.6 ~ 2.45 |
| Mica content (%) | 90 |
| Flexural force (Mpa) | 150 |
| Dielectric strenght (MV/m) | 10 |
| Maximum temperature | 1022°F (550°C) |
| Continuous Temperature | 932°F (500°C) |
| Sheet size | 600 mm X 1000 mm ou 1000 mm X 1200mm |
N.B. The information presented may differ from practice. We recommend conducting tests according to the conditions of use. We accept no responsibility for results obtained by the application of this information or the safety and suitability of our products. The data is subject to certain variations without notice.
